PH006 – SCANNER .46-.55 SCALE 1:7 ARF

PH006 – SCANNER .46-.55 SCALE 1:7 ARF

Introducing

     If you are looking for an Almost Ready to Fly R/C model, which is easy to assemble and exciting to fly, the Scanner is for you.This low wing was designed from the start to handle any kind of aerobatic maneuvers. It loops, rolls, flies inverted, and is capable of many more magical moves. It's a flying cocktail of performance. All the hardware are included (servo wire, fuel tank, wheel/landing gear, etc). You only need to seperately purchase the nitro engine and radio system, and can fly this plane after 1-2 hours of installation.

Technical data

- Wingspan: 1444mm (56.8in)
- Length: 1168mm (45.9 in)
- Flying weight: 2400-2600 gr
- Wing area: 35.2 dm2
- Wing loading: 70g/dm2
- Wing type: Naca airfoils
- Covering type: V-kote film
- Spinner size: Plastic 58mm (included)
- Radio: 4 channel minimum (not included)
- Servo: 5 standard servo: 2 aileron; 1 elevator; 1 rudder; 1 throttle (not included)
- Recommended receiver battery: 4.8-6V / 800-1200mAh NiMH (not included)
- Servo mount: 21mm x 42 mm
- Propeller: suit with your engine
- Engine: .46-.55 / 2-stroke (not included)
- Motor: brushless outrunner 1000-1400 W, 480 KV (not included)
- Experience level: Intermediate
- Plane type: Low wing sport
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: RIMFIRE .46 (not included)
- Lipo cell: 4-6cells / 4000-5000mAh (not included)
- Esc: 50-70A (not included)

Feature

- Designed for compatibility with both GP and EP flight
- Extremely lightweight laser-cut all-wood construction
- All hardware included

Colour chart

Not update...

Packing

BOX DIMENSION
   -1044mm X 430mm X 105mm (L x W x H)
