GL09 - ASW 28 ELECTRIC COMPACT 5,5m 216,5" ARF CARBON

GL09 - ASW 28 ELECTRIC COMPACT 5,5m  216,5

Introducing

ASW 28 ELECTRIC COMPACT 5,5m  216,5" ARF CARBON

Technical data

- Wingspan: 5500mm (216.53 in)
- Length: 2236mm (88.03 in)
- Flying weight: 9850gr – 10050gr
- Wing area: 111 dm2
- Wing type: HQ - Wortmann airfoils
- Radio: 4 channel minimum (not included)
- Servo:  4 standard hi-torque servo: 2 aileron; 1 elevator; 1 rudder (not included)
- Flap: 2 electric flaps 440mm (not included)
- Spinner size: Aluminum H hub propeller holder, shaft 8mm (not included)
- Motor: brushless outrunner 2141-2263 W, 195 KV (not included)
- Experience level: Intermediate
- Plane type: Glider
RECOMMENDED MOTOR AND BATTERY SET UP
- Motor: Hacker A60-24S V2 28 pole, KV:195 (not included)
- Lipo: 6cells X 2  (not included)
- Esc: 100A (not included)

Feature

- Fuselage with 02 pieces
- Wing with 02 pieces
- Composite material for super strong and light weight
- True-to-scale artwork
- High-quality hardware package included

Colour chart

Not update...

Packing

BOX DIMENSION
   -1709mm X 640mm X 318mm (L x W x H)
