PH214 - RED YAK 54 2,5m 98,5" 120cc ARF CARBON

PH214 - RED YAK 54 2,5m 98,5

Introducing

RED YAK 54 2,5m 98,5" 120cc ARF CARBON

Technical data

- Wingspan: 2500mm (98.5 in)
- Length: 2364mm (93 in)
- Flying weight: 11750-12000 gr
- Wing area:  111 dm2
- Gear type: Carbon fiber for main gear (included)
- Spinner size: 95mm (included)
- Radio: 6 channel minimum (not included)
- Servo: 9 standard hitorque servo (up 25kg): 4 aileron; 2 elevator; 2 rudder; 1 throttle (not included)
- Propeller: suit with your engine
- Engine: 120CC Gas engine (not included)
- Ailerons:
   Low rate: 18-20 degrees, 30-40% exponential
   High rate: 40-45 degrees, 50-60% exponential
- Elevators:
   Low rate: 10-12 degrees, 18-20% exponential
   High rate: 45-60 degrees, 50-60% exponential
- Rudder:
   Low rate: 20 degrees, 50-60% exponential
   High rate: 45-55 degrees, 60-80% exponential
- Experience level: Intermediate
- Plane type: Aerobatic

Feature

- Capable of both precise and extreme 3D aerobatics
- Designed for compatibility with both GP flight
- Bolt-on two-piece wing for easy transport and setup at the field
- Removable canopy for easy change lipo battery and set up radio
- Composite material for super strong and light weight.
- Durable factory-painted fiberglass cowl
- All hardware included

Colour chart

Not update...

Packing

  - 1859mm X 715mm X 388mm (L x W x H)
